AlN-TL80

AlN-TL80

Aluminum nitride large particle filler powder is produced by self developed aluminum nitride powder.After spraying,granulation and sintering,it is screened and packed. The products are widely used in TIM(thermal interface material).

SpecificationsAlN-TL30AlN-TL50AlN-TL80AlN-TL100AlN-TL120
D50/um 35(±5)50(±5)80(±5)100(±5)120(±5)
Appearance   White
Spherical>95%>95%>95%>95%>95%
g·cm-3(Apparent density)1.5~1.61.6~1.71.65~1.751.65~1.751.65~1.75
g·cm-3(Tap density)1.8~1.91.85~2.051.95~2.1 1.95~2.11.95~2.1
0/wt%<2<2<2<2<2
AIN/wt%>96>96>96 >96>96
